Specifications:
– 4 channel DMX Bar
– 16 built in Chase patterns
– Chases run by audio and preset Slow, Medium, & Fast speeds
– DMX control activates Stand by, 16 built chases, 7 built in scenes and 4 channel-manual dimmer mode to be controlled by external DMX controller
– 7 built in static Scenes to be played back by DMX
– Linkup function for Master/Slave modes
– One three prong Edison socket per channel
– Four LEDs display channel activity
– External channel fuses for quick and easy replacement
– 3 pin XLR DMX Input & Output
– One 3 pin XLR foot controller input
– 4 mounting knobs for Par Cans
– 1 adapter for stand mount (For use with LTS-3 stand)
– Control via DMX with the Elation; DMX Operator Pro, Scene Setter, Scene Setter-48 and Stage Desk-16, DMX Operator I, DMX Operator II
– Optional foot controller model T16-FS (sold separately)
– Maximum Load: 5A per channel / 15A total
