Specificaties:
Power Rating 75W/Channel @ 8 Ohms
Channels 8
Damping Factor Not Specified by Manufacturer
Input Sensitivity 1.4V
Frequency Response 20Hz – 20kHz 0.5dB
Signal-to-Noise Ratio 110dB
Total Harmonic Distortion (THD) < 0.05%
Intermodulation Distortion (SMPTE) < 0.05%
Crosstalk > 70dB
Common Mode Rejection Ratio > 55dB, > 70dB Typical
Connectors 8 x 3-Pin Phoenix Inputs 8 x 2-Pin Phoenix Outputs 1 x Power Input
Controls 8 x Input Attenuator Knobs 1 x Set of Amp Control DIP-Switches 1 x Power Switch
Indicators 1 x Power LED 8 x Signal LEDs 8 x Clip LEDs 8 x Thermal LEDs 8 x Fault LEDs
Cooling Convection
Power Consumption Not Specified by Manufacturer
Power Requirements Universal Power Supply
Dimensions (HxWxD) 1.75 x 19 x 14.25″ (44 x 483 x 362mm)
Weight 10 lbs (4.54kg)
