- Contact resistance: ≤ 3 mΩ
- Dielectric strength: 4 kVdc
- Insulation resistance: > 0.1 GΩ (after damp heat test IEC 68-2-30)
- Rated current per contact: 20 A
- Rated voltage: 250 V
- Cable O.D.: 5 – 15 mm
- Lifetime: > 1000 mating cycles
- Wiring: flat tabs for 3/16" (FASTON® 4.8 x 0.5 mm) or soldering
- Locking device: Quick Lock
- Mounting direction: front
- Chassis shape: D-size
- Approvals: UL,VDE,Electroswiss
- Flammability: UL 94 HB
- Protection class: IP 20 (mated)
- Savety requirements: EN/IEC 61984
- Solderability: Complies with IEC 68-2-20
- Temperature range: -30 °C to +80 °C
