All-in-One 4K controller with scaler and PIP
HDR10 supported
DVI / DP1.2 / HDMI 2.0 / 12G SDI
8/10/12-bit Colour Depth
16x Gigabit Ethernet output port
4x Fibre optical output port
GENLOCK
The NovaPro UHD Jr is a new all-in-one 4K controller which combines excellent video processing capabilities, scaler and sending card functions into one housing. It can handle a variety of video input signals like DVI, DP1.2, HDMI2.0 and 12G SDI.
It can support 4K x 2K@60Hz, but also ultra-high resolutions up to 8K x 1K@60Hz. When using mosaic mode, multiple UHD Jr units can be combined to build even bigger screen setups.
Due to the build in pixel to pixel scaling function an external scaler is no longer necessary.
NovaPro UHD Jr also supports HDR10 (only with A8S/A10S receiving card) to greatly enhance the display image quality.
Control can be done with V-Can and (Smart) LCT Software.
The NovaPro UHD Jr is equipped with Neutrik Ethernet ports and optical fiber ports.
Due to the professional interfaces, excellent image quality and flexible image control the NovaPro UHD Jr is well suited for stage control systems, conference sites, exhibition sites and other high-end rental applications as well as fine-pitch LED displays.
Input resolution DVI: Up to 1920×1200@60Hz
Input resolution DP1.2: Up to 3840×2160@60Hz
Input resolution HDMI2.0: Up to 3840×2160@60Hz
Input resolution SDI(12G): Up to 4096×2160@60Hz
Capacity: >10.4 million pixels
Bit Depth Of Video Resource: 8/10/12bit
Control Method: USB / Network / RS232 Interface
Output Interface: 16x Ethernet output ports
Output Interface: 4x Fiber output ports(2xMain / 2xBack-up)
Monitor output: 1x HDMI
Output Loop: 1x HDMI2.0
Output Loop: 2x 12G SDI
Gen Lock: Input / Loop
Supply Voltage: AC-100-240V-50/60HZ
Power consumption: 70Watt
Dimensions: 482.6×396.5x139mm
Weight: 6.3Kg
Operating temperature: 0 ~ +50°
For most recent software please check Novastar website: http://www.novastar.tech/download/
